| Specification | LM-3015E/PM |
|---|
| Viewing Angle | 60/70/70/70 degree (U/D/L/R) |
| Response Time | 3 ms (Raising) / 5 ms (Falling) |
| Resolution | Up to 1024 x 768 |
| Pixel Pitch | 0.192 (H) x 0.192 (V) |
| Pixel Arrangement | RGB Vertical Stripe |
| LCD | 15″ TFT LCD |
| Interface | VGA |
| Contrast Ratio | 600:1 |
| Brightness | 350 cd/m2 |
| Active Area | 196.61 (H) x 147.46 (V) |
| Power Supply | |
|---|
| Power Supply | 12V from Posiflex terminal VGA port |
| Touch | |
|---|
| Touch Type | Bezel-free PCAP touch |
| Interface | USB |
| Support | |
|---|
| System Supported | 10.1″ & 15″ & 17″ KS Series |
| VESA Mounting Support | – |
| Options | |
|---|
| Options | – |
