| System-Configuration | XT-3915IR-G2 |
|---|
| Processor | Intel Elkhart Lake Celeron J6412, up to 2.60 GHz, 1.5M Cache |
| System Memory | DDR4 SO-DIMM slot x 2, max. 32GB |
| Storage Device | M.2 connector x 2 (support SATA signal only) |
| RAID Function | N/A |
| Intel vPro Support | N/A |
| TPM | TPM 2.0 |
| Power Supply | 12V/60W |
| OS Support | Windows 10 IoT LTSC / Windows 11 IoT LTSC |
| Display & Touch | |
|---|
| LCD | 15″ TFT LCD |
| Resolution | 1024 x 768 |
| Touch | IR touch |
| I/O Expansion | |
|---|
| Serial Port | DB9 x 3 + RJ50 x 1 + COM5/COM6 via optional converter cable from service window, 5V support on all COM ports, 12V support on COM1 to COM4 |
| Parallel Port | via optional conversion cable through service window |
| Standard USB Port | USB 3.0 x 3 + USB 2.0 x 4 |
| PoweredUSB Port | N/A |
| LAN Port | 10/100/1000 Mb x 1 |
| Display Port | VGA x 1 (12V support for Posiflex monitors) |
| CR Port | RJ11 x 1, control 2 CR via optional Y-cable, support 24V cash drawer |
| Audio | Internal 2W speaker x 1 |
| Expansion Slot | M.2 slot x 1 |
| Dimension | |
|---|
| Dimension (W x D x H in mm) | 372 x 252.7 x 320 |
| Weight (N. W. in kg) | 6 |
| Environmental | |
|---|
| Operating Condition | 0°C – 40°C, 20%RH – 90%RH |
| Storage Condition | -20°C – 70°C, 10%RH – 90%RH |
| Built-In Options | |
|---|
| WiFi module | M.2 WiFi/BT module |
| Camera Module | N/A |
| Printer Module | N/A |
| AG Glass | N/A |
| Attachment Options | |
|---|
| POS Monitor | PCAP touch TFT LCD: 9.7″/14″/15″
Non-touch TFT LCD: 7″/9.7″/12.1″/14″/15″
Resistive touch TFT LCD: 15″ |
| Line Display | 2 x 20 rear-mount VFD/LCD customer line display; 7″ color LCD graphical customer line display |
| External UPS Pack | N/A |
| Attachment | MSR; iButton; Rotatable 2D Scanner; RFID; Fingerprint Sensor; Keypad |
