| Display | TM-5016C |
|---|
| Viewing Angle | 89/89/89/89 degree (U/D/L/R) |
| Response Time | 25 ms |
| Resolution | 1920 x 1080 |
| Pixel Arrangement | R.G.B. Vertical Stripe |
| LCD | 15.6″ TFT LCD |
| Contrast Ratio | 1000:1 |
| Brightness | 300 nits |
| Active Area | 344.16 (H) x 193.59 (V) |
| Specification | |
|---|
| Weight [N. W. in g] | 1.7 |
| USB Port | 1 x USB type B |
| Power Supply | 1 x 12V DC-IN (minimum 18W) or 1 x 12V from USB-C Posiflex terminal |
| Keypad | OSD Keypad (OSD, EXT, ＋, －/ Power Button) |
| Display Interface | 1 x USB-C, 1 x DP, 1 x HDMI, 1 x VGA |
| Dimension [W x D x H in mm] | 372.8 x 239.3 x 33.0 mm |
| Touch | |
|---|
| Touch Type | Bezel-free PCAP touch |
| Interface | USB |
| Support | |
|---|
| System Supported | Gen9 base |
| VESA Mounting Support | VESA 100
VESA 75 |
| Built-in options | |
|---|
| Camera | 1 MP wide angle |
| Barcode Scanner | 2D Barcode Scanner |
| Attachment Options | |
|---|
| Side attachment | ZA-101, ZA-103, ZA-104, ZA-303, ZA-304, ZA-305 |
