| Specification | SA-715Z |
|---|
| Software Program | – |
| Scanner Rotatable Angle | 30° frontward / 105° backward (along z-axis); 25° sideward (along y-axis) |
| Scan Rate | Up to 60 fps |
| Scan Method | CMOS array sensor |
| Scan Angle | Horizontal – 41°, Vertical – 26° |
| Resolution | 752 (H) x 480 (V) pixels |
| Number of Keys | – |
| Magnetic Stripe Reading | – |
| Light Source | White LED x 2 |
| Interface | – |
| Depth of Field | 40~120 mm (15 mils QR code) |
| Support | |
|---|
| 1D Barcode Support | JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2 of 5, Interleaved 2 of 5, ISBNISSN-ISMN, Matrix 2 of 5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey |
| 2D Barcode Support | Aztec Code, Aztec Runes, Chinese Sensible code, Codablock F, Composite codes, Data Matrix (ECC200/EC0-140), Maxi Code (mode 2~5), MicroPDF41, QR & Micro-QR Code, PDF417 |
| Postal Code Support | Chinese Post, Intelligent Mail Barcode, Korean Postal Authority code |
| System Supported | 15″/17″ XT Series & PS Series |
| Options | |
|---|
| Options | – |
