| Specification | RA-104 |
|---|
| Scanner Rotatable Angle | 110° tilt; 180° swivel |
| Scan Rate | Up to 60 fps |
| Scan Method | CMOS array sensor |
| Scan Angle | Horizontal – 41°, Vertical – 26° |
| Resolution | 752 (H) x 480 (V) pixels |
| Light Source | White LED x 2 |
| Interface | USB |
| Depth of Field | 40~120 mm (15 mils QR code) |
| Support | |
|---|
| 1D Barcode Support | JAN/UPC/EAN (add-on), Codabar/NW-7, Code 11, Code 39, Code 93, Code 128,
GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2 of 5,
Interleaved 2 of 5, ISBN-ISSN-ISMN, Matrix 2 of 5, MSI/Plessey,
S-Code, Telepen, Tri-Optic, UK/Plessey |
| 2D Barcode Support | Aztec Code, Aztec Runes, Chinese Sensible Code, Codablock F, Composite Codes,
Data Matrix (ECC200), Passport MRZ (OCR-B), Maxi Code (mode 2~5),
MicroPDF417, Micro QR Code, PDF417, QR Code |
| Postal Code Support | Chinese Post, Intelligent Mail Barcode, Korean Postal Authority Code, POSTNET |
| System Supported | RT Series 15″/15.6″, GT Series 15″/15.6″, HC Series |
