| Component Name | Specification |
|---|
| Series Name | OH Series |
| Screen Size | 75″ |
| Panel Technology | 120Hz E-LED BLU |
| Resolution | 3,840 x 2,160 (16:9) |
| Brightness | 3,500 nit |
| Contrast Ratio (Typical) | 1,200:1 |
| Viewing Angle (H/V) | 178/178 |
| Response Time | 14ms |
| Panel Orientation | Portrait/Landscape |
| External Control | RS232C (In), RJ45 (In) |
| RGB Input | DP 1.2 |
| VIDEO Input | HDMI 2.0 (2) |
| Audio Output | Stereo Mini Jack |
| HDCP Input | HDCP 2.2 |
| Power Supply | AC 100 – 240 V, 50/60 Hz |
| Power Consumption (Typical/Max) | 471 / 1200 W |
| General Feature | Internal |
| BTU (Max) | 4095 |
| Sleep Mode | Less than 0.5W |
| Operating Temperature | -30℃~ 50℃ |
| Operating Humidity | 10~80% (Non-condensing) |
| IP Rating | IP56 |
| Key Features | Power-box Integrated, IP56 Outdoor, Built-in MagicInfo Player S7, SSSP 7.0 |
| Special | IP56 Rated Simple Enclosure Outdoor, Protection Glass(IK-10 Level, Anti Graffiti, Infrared Reduce), Polarized Sun Glasses Viewable in any direction, Portrait /Landscape Installation Support, Auto Brightness Control with Ambient Brightness Sensor, Temperature Sensor, RJ45 MDC, Auto Source Switching & Recovery, Clock Battery(80hrs Clock Keeping) |
| 24/7 Operation | Yes |
| System On Chip | Yes |
| Processor | Cortex A72 1.7GHz Quad-Core CPU |
| On-Chip Cache Memory | L1 Instruction Cache : 48KB
L1 Data Cache : 32KB
L2 Cache : 2MB |
| Clock Speed | 1.7GHz |
| Main Memory Interface | 2.5GB LPDDR4 1.6GHz 64bit |
| Graphics | Graphic resolution: 1,920 x 1,080
Output resolution: up to 3,840 x 2,160 (Scale up from graphic processing result.)
Supports OpenGL ES |
| Multimedia | Video Decoder FHD MFD: VP8, H.264, AVS+(60Hz)
UHD MFD: HEVC, H.264, VP95K HEVC Decoder, SHVC(ATSC3.0) AVS2.0 HEVC / AVS2.0 1xUHD120p (DP_NR off, FRC bypass)
Audio Decoder: AC3 (DD), MPEG |
| IO Ports | USB 2.0 |
| Operating System | Tizen 5.0 (VDLinux) |
| Storage (FDM) | 8GB (3.88GB Occupied by O/S, 4.12GB Available) |
| Product Dimensions (mm) | 1774.8 x 1053.4 x 130 |
| Package Dimensions (mm) | 1932 x 1251 x 367 |
| Bezel Width (mm) | 59.8 / 59.8 / 59.8 / 59.8 |
| Mounting Hole | 870 x 1118.4 (M8 x 4Hole), 260 x 1118.4 (M8 x 4Hole) |
| Product Weight | 134 kg |
| Package Weight | 150 kg |
| Included in Box | Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote Controller, Batteries |
| USB | USB (1) |
| Protection Glass | 5T Tempered Glass |
| Safety | 60950-1 |
| EMC | Class A |
