| Component Name | Specification |
|---|
| Pixel Pitch | 1.5 ㎜ |
| Pixel Configuration | 1 red, 1 green, 1 blue |
| Diode Type | Surface Mount Device (SMD) |
| Configuration (LxH, per screen) | 1920 x 1080 pixels |
| Dimensions (inch, per screen) | 113.7 x 64.1 x 2.2 in. (2.4 in. total depth with wall mount) |
| No. of Modules (WxH, per screen) | 12 x 9 |
| Weight (per screen) | 275.6 lbs |
| Dimensions (inch, DiagonalxD, per screen) | 130 x 2.2 inch |
| Brightness (Default/Max) | 1,000 nit / 500 nit |
| Contrast Ratio (in Darkroom) | 6,000 : 1 |
| HDR Compatibility | LED HDR / AI Picture |
| Viewing Angle – Horizontal | 160° |
| Viewing Angle – Vertical | 160° |
| Bit Depth (Gray Scale Intensity) | 16 bit (Internal processing 20bit) |
| Color Temperature (White Point) – Default | 6,500K ± 500K (Floating bin) |
| Color Temperature (White Point) – Adjustable | 2,800K ~ 10,000K |
| Video Rate | 50/60 Hz |
| Input Power Range | 100~240 VAC, 50/60 Hz |
| Power Consumption (Max) | 1,700 W/Screen |
| Power Consumption (Typical) | 685 W/Screen |
| Power Consumption – Standby | less than 0.5W |
| Heat Generation – Typ | 2,337 BTU/Screen |
| Refresh Rate | 3,840 Hz |
| Heat Generation – Max | 5,800 BTU/Screen |
| Visual Refresh Rate | 7,680 Hz |
| Working Temperature / Humidity | 0℃~+40℃ / 10%~80%RH |
| Storage Temperature / Humidity | -20℃~+45℃ / 5%~95%RH |
| IP Rating | IP20 |
| LED Lifetime | 100,000 hours |
| Package Weight (lbs, per cabinet) | 463 lbs |
| Box Dimension (inches, WxHxD) | 72.4 x 72.7 x 23.4 (without pallet)
72.8 x 78 x 32.1 (with pallet) |
| Safety | 62368-1, 60950-1 |
| EMC | Class A |
| Eye-protection | TUV Eye Comfort |
| Service | Front |
| Operating System | Tizen 6.5 |
| MagicINFO | Yes |
| Sensor | Temperature, Humidity, Eco Sensor |
| Other Features | AI Picture, LED HDR, Dynamic Peaking, Workspace (Microsoft365/VMWare/RDP), Auto Source Switching & Recovery, Dicom Simulation Mode, SmartView+ |
| Controller | Built-in |
| Input (Video) | DP 1.2 (1), HDMI 1.4 (3), USB 2.0 (2) |
| Output | Audio (Stereo mini Jack) / eARC |
| WiFi / BT | O/O |
| External Control | RS232C(in), RJ45 |
| Speaker | 10W 2ch |
| Accessories | Décor Frame, Frame Kit, Buffer parts |
| Remote Control | IR Remote Controller |
| Special Installation | Side by Side Installation with additional frame kit (up to 4 screens) |
